The THUNDER 1500HD is a heavy duty IPM motor drive built for demanding material handling and mobility applications. Its sealed, rugged design supports outdoor use, and the dual-stage helical gearing delivers smooth, reliable torque for moving heavy loads. With a high-performance interior permanent magnet motor and hardened carbon-steel axle, the THUNDER 1500HD offers lasting strength, durability, and precision.
MARKETS
- Material Handling
- Mobile Robot & AGVs
- Outdoor Power Equipment
FEATURES
- Sealed drive system:
Rugged; usable outdoors - Optional:
Electromagnetic power-off brake - Motor:
Interior permanent magnet, 140 mm diameter, brushless 48 volt with internal encoder and thermal sensor, connectors, IP69K conformity - Axle Material:
Hardened carbon steel - Gear:
Dual stage helical - Reduction ratio:
21:1 and 31:1
PERFORMANCE EXAMPLES
Low Speed (31:1 ratio)
| Duty Type | S2-2min | S2-10Min | S2-30min | S2-60min |
|---|---|---|---|---|
| Torque, Nm | 883 | 589 | 368 | 282 |
| Power, kW | 2.98 | 5.97 | 4.97 | 3.34 |
| RPM | 32 | 97 | 129 | 113 |
| Efficiency | 58% | 81% | 86% | 88% |
| Phase Current, Amps | 200 | 140 | 100 | 65 |
| Stator Frequency, Hz | 83 | 250 | 333 | 292 |
High Speed (21:1 ratio)
| Duty Type | S2-2min | S2-10Min | S2-30min | S2-60min |
|---|---|---|---|---|
| Torque, Nm | 596 | 397 | 248 | 191 |
| Power, kW | 2.98 | 5.97 | 4.97 | 3.34 |
| RPM | 48 | 143 | 191 | 167 |
| Efficiency | 58% | 81% | 86% | 88% |
| Phase Current, Amps | 200 | 140 | 100 | 65 |
| Stator Frequency, Hz | 83 | 250 | 333 | 292 |
